GlazeGuard®

1000 WR+

Panel Thickness

Polypropylene stabilizers and
EPS or ISO foam combine to make this panel a nominal 1″.

R-Value

As an alternative to glass, this
panel offers an R-Value of
4.19 (EPS) and 6.13 (ISO).

Panel Weight

This panel has a nominal
weight of approximately 0.80 to
1.23 lbs per square foot.

Cut to Size

These panels can be easily cut
to the correct dimension on site
using standard tools.

Water Resistant

The plastic core of these panels offers extra protection from incidental moisture.

Quick Lead Time

Available nationwide, these
panels can be found locally or shipped within two weeks.

Water Resistant Infill Solution with Increased Thermal Value

Panel

Smooth Skins

Textured Skins

Composition

  • .010″ Textured Aluminum
  • (or) .024″ Smooth Aluminum
  • 3mm Polypropylene
  • 11/16″ Expanded Polystyrene
  • (or) 11/16″ Polyisocyanurate
  • 3mm Polypropylene
  • .010″ Textured Aluminum
  • (or) .024″ Smooth Aluminum

Standard Sizes

  • 48″ x 96″ (121.9cm x 243.8cm)
  • 48″ x 120″ (121.9cm x 304.8cm)
  • 48″ x 144″ (121.9cm x 365.8cm)
  • 60″ x 96″ (152.4cm x 243.8cm)
  • 60″ x 120″ (152.4cm x 304.8cm)
  • 60″ x 144″ (152.4cm x 365.8cm)

System Moldings

No extrusions are used for this product.  The panel is glazed into a window (or storefront) extrusion, by others.
