SinoCore®

1pc Moldings

Panel Thickness

A fluted, 4mm high density polypropylene core makes this a lightweight cladding option.

System Depth

The system measures 7/16″ from the face of the substrate to the face of the moldings.

Panel Weight

This panel has a nominal weight
of approximately 0.58 to 0.77
lbs per square foot.

Barrier Wall

This system is designed to be completely sealed to keep all
moisture away from the structure.

Water Resistant

The plastic core of these panels offers extra protection from incidental moisture.

Flat Moldings

One-piece, low-profile aluminum moldings capture the panel edge and fit close to the face.

Lightweight Cladding in an Easy-To-Install System

Panel

Batten Moldings

Reveal Moldings

Composition

.010″ Textured Aluminum
(or) .024″ Smooth Aluminum
4mm Polypropylene
.010″ Primed Aluminum

Standard Sizes

48″ x 96″ (121.9cm x 243.8cm)
48″ x 120″ (121.9cm x 304.8cm)
48″ x 144″ (121.9cm x 365.8cm)
60″ x 96″ (152.4cm x 243.8cm)
60″ x 120″ (152.4cm x 304.8cm)
60″ x 144″ (152.4cm x 365.8cm)

System Moldings

E-301 Horz/Vert
E-302 Outside Corner
E-303 Inside Corner
E-304 Perimeter J
E-305 Drip Edge
E-306 Horz/Vert (Reveal)
